| Safe working load | 450KG | 450KG | 320KG | 320KG | 230KG |
| Extended table safe working load | 113KG | 113KG | 113KG | 113KG | 113KG |
| Maximum working platform | 7.8M | 9.8M | 11.8M | 13.8M | 15.8M |
| Maximum platform height | 5.8M | 7.8M | 9.8M | 11.8M | 13.8M |
| Working platform size (length*width) | 2.27*1.13M | 2.27*1.13M | 2.27*1.13M | 2.27*1.13M | 2.63*1.13M |
| Overall dimensions (unfolded) | 2.391.162.21M | 2.391.162.34M | 2.391.162.47M | 2.391.162.6M | 2.791.242.6M |
| Overall dimensions (folded) | 2.391.161.7M | 2.391.161.82M | 2.391.161.94M | 2.391.162.06M | 2.791.242.06M |
| Extended dimensions of table | 0.9M | 0.9M | 0.9M | 0.9M | 0.9M |
| Minimum ground clearance | 106MM/29MM | 106MM/29MM | 106MM/29MM | 106MM/29MM | 106MM/29MM |
| Turning radius (inner wheel/outer wheel) | 0/2.5M | 0/2.5M | 0/2.5M | 0/2.5M | 0/2.5M |
| Lifting/driving motor | DC: 24V/4.5KW AC: 24V/3.4KW | DC: 24V/4.5KW AC: 24V/3.4KW | DC: 24V/4.5KW AC: 24V/3.4KW | DC: 24V/4.5KW AC: 24V/3.4KW | DC: 24V/4.5KW AC: 24V/3.4KW |
| Wheelbase | 1865mm | 1865mm | 1865mm | 1865mm | 1865mm |
| Lifting speed | 3-5m/min | 3-5m/min | 3-5m/min | 3-5m/min | 3-5m/min |
| Machine speed (folded) | 3.5km/h | 3.5km/h | 3.5km/h | 3.5km/h | 3.5km/h |
| Machine speed (lifted) | 0.8km/h | 0.8km/h | 0.8km/h | 0.8km/h | 0.8km/h |
| Battery | 4*6v/200ah | 4*6v/200ah | 4*6v/200ah | 4*6v/200ah | 4*6v/240ah |
| Charger | 24V/30A | 24V/30A | 24V/30A | 24V/30A | 24V/30A |
| Maximum climbing ability | 25° | 25° | 25° | 25° | 25° |
| Maximum allowable working angle | 1.5°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° |
| Tire | Φ381×127MM | Φ381×127MM | Φ381×127MM | Φ381×127MM | Φ381×127MM |
| Machine weight | 2100KG | 2250KG | 2550KG | 2950KG | 3300KG |
